大学化学 >> 2020, Vol. 35 >> Issue (3): 89-93.doi: 10.3866/PKU.DXHX201907032

化学实验 上一篇    下一篇

用SolidWorks软件辅助设计物理化学实验设备

樊玲*(),尚贞锋

  • 收稿日期:2019-07-24 录用日期:2019-11-25 发布日期:2019-12-04
  • 通讯作者: 樊玲 E-mail:fling@nankai.edu.cn

Applications of SolidWorks Software for Design Equipments for Physical Chemistry Experiments

Ling Fan*(),Zhenfeng Shang

  • Received:2019-07-24 Accepted:2019-11-25 Published:2019-12-04
  • Contact: Ling Fan E-mail:fling@nankai.edu.cn

摘要:

结合实例介绍采用SolidWorks软件设计物理化学实验仪器设备。证明SolidWorks软件用于设计仪器设备不仅大大节省了设计的时间和成本,并且还能提高了设计的效率和效果。

关键词: 物理化学实验, SolidWorks软件, 辅助设备设计

Abstract:

The application of SolidWorks software for design of physical chemistry experiment instruments is introduced using a design example. The design example demonstrates the power of SolidWorks software in the design of equipment. Application of the software can not only reduce the time and cost, but also improve the efficiency and effectiveness for the design.

Key words: Physical chemistry experiment, SolidWorks software, Design of auxiliary equipment

MSC2000:

  • G64
