大学化学 >> 2023, Vol. 38 >> Issue (2): 266-270.doi: 10.3866/PKU.DXHX202205025

自学之友 上一篇    下一篇

休克尔分子轨道法处理CnHn (n = 4和8)体系的π键键级的释疑

王慧婷, 石小飞, 魏东辉()

  • 收稿日期:2022-05-18 录用日期:2022-06-13 发布日期:2022-06-24
  • 通讯作者: 魏东辉 E-mail:donghuiwei@zzu.edu.cn
  • 基金资助:
    国家自然科学基金面上项目(21773214);河南省自然科学基金优秀青年科学基金项目(212300410083);河南省高等学校青年骨干教师培养计划(2020GGJS016)

Elucidation on the Treatment of π Bond Order of CnHn (n = 4 and 8) Systems Using Hückel Molecular Orbital Method

Huiting Wang, Xiaofei Shi, Donghui Wei()

  • Received:2022-05-18 Accepted:2022-06-13 Published:2022-06-24
  • Contact: Donghui Wei E-mail:donghuiwei@zzu.edu.cn

摘要:

休克尔分子轨道(HMO)法对C4H4和C8H8单环多烯体系进行处理时会将其默认为共轭离域的三重态分子,这与其真实分子的单重态结构不符。运用密度泛函理论(DFT)分别对其单重态和三重态进行结构优化,并计算出更为精确的四元环、八元环的π键键级。基于DFT计算结果,我们提出了解决HMO法计算C4H4和C8H8单环多烯体系的π键键级误差的方案。

关键词: HMO方法, 密度泛函理论, π键键级, 键长

Abstract:

The C4H4 and C8H8 monocyclic polyene systems are treated automatically as the conjugated delocalized triplet molecules by Hückel molecular orbital (HMO) method, but this is inconsistent with their actual ground state structures associated with singlet state. In this work, both the singlet and triplet molecular structures of the four-membered ring and the eight-membered ring were optimized by density functional theory (DFT), and the more accurate π bond orders were calculated. Based on the DFT calculated results, we suggested a solution that can correctly compute the π bond orders in the C4H4 and C8H8 monocyclic polyene systems by using the HMO method.

Key words: HMO method, Density functional theory, π Bond order, Bond length
