Introduction to a Novel Visual Method for the Treatment of Kinetic Data

Heng Zhang()

College of Chemistry and Molecular Sciences, Wuhan University, Wuhan 430072, China

Received:2020-05-11 Accepted:2020-06-18 Published:2020-06-29
Contact: Heng Zhang E-mail:hengzhang@whu.edu.cn

Abstract

Abstract:

Kinetic data treatment is one of the paramount contents of the kinetics in physical chemistry. There have been imperfections in the classical kinetic data treatment when faced with modern monitoring techniques which can supply extensive experimental data. Recently, variable time normalization analysis is raised to solve the above problems. With only several experiments under real experimental conditions, the rate constant and reaction order of the reactants and catalyst can be deduced by using visual comparison with the help of spreadsheet.

Key words: Kinetic data, Reaction order, Integration method, Visual method

Heng Zhang. Introduction to a Novel Visual Method for the Treatment of Kinetic Data[J].University Chemistry, 2021, 36(4): 2005032.

实验	[A]₀/(mol?L^-1)	[B]₀/(mol?L^-1)	[C]₀/(mol?L^-1)
1	1.0	1.0	0.01
2	0.7	1.0	0.01
3	1.0	0.7	0.01
4	1.0	1.0	0.05

t/min	[A]/(mol?L^-1)				[B]/(mol?L^-1)				[P]/(mol?L^-1)
t/min	Exp1	Exp2	Exp3	Exp4	Exp1	Exp2	Exp3	Exp4	Exp1	Exp2	Exp3	Exp4
0	1.000	0.7000	1.000	1.000	1.000	1.000	0.7000	1.000	0	0	0	0
2	0.89286	0.62378	0.92378	0.78844	0.89286	0.92378	0.62378	0.78844	0.10714	0.07622	0.07622	0.21156
6	0.73529	0.50719	0.80719	0.55402	0.73529	0.80719	0.50719	0.55402	0.26471	0.19281	0.19281	0.44598
12	0.5814	0.3881	0.6881	0.38315	0.5814	0.6881	0.3881	0.38315	0.4186	0.3119	0.3119	0.61685
20	0.45455	0.28637	0.58637	0.2715	0.45455	0.58637	0.28637	0.2715	0.54545	0.41363	0.41363	0.7285
30	0.35714	0.20669	0.50669	0.19901	0.35714	0.50669	0.20669	0.19901	0.64286	0.49331	0.49331	0.80099
42	0.28409	0.14688	0.44688	0.15072	0.28409	0.44688	0.14688	0.15072	0.71591	0.55312	0.55312	0.84928
56	0.22936	0.10294	0.40294	0.11746	0.22936	0.40294	0.10294	0.11746	0.77064	0.59706	0.59706	0.88254
72	0.18797	0.07107	0.37107	0.09381	0.18797	0.37107	0.07107	0.09381	0.81203	0.62893	0.62893	0.90619
90	0.15625	0.04824	0.34824	0.07648	0.15625	0.34824	0.04824	0.07648	0.84375	0.65176	0.65176	0.92352

1	武汉大学物理化学教研组. 物理化学(下), 第2版武汉: 武汉大学出版社, 2010.
2	Burés J. Angew. Chem. Int. Ed. 2016, 55, 2028. doi: 10.1002/anie.201508983
3	Burés J. Angew. Chem. Int. Ed. 2016, 55, 16084. doi: 10.1002/anie.201609757
4	Martinez-Carrion A. ; Howlett M. G. ; Alamillo-Ferrer C. ; Clayton A. D. ; Bourne R. A. ; Codina A. ; Vidal-Ferran A. ; Adams R. W. ; Burés J. Angew. Chem. Int. Ed. 2019, 58, 10189. doi: 10.1002/anie.201903878
5	Nielsen C. D. T. ; Burés J. Chem. Sci. 2019, 10, 348. doi: 10.1039/C8SC04698K
6	张恒; 汪存信. 大学化学, 2009, 24 (6), 65.
